Sturdy and waterproof electrical box for worksite with 2P+T 16A single-phase sockets and electrical protection included. Ready to use, the electrical box is pre-cabled. It is fitted with a 40A 30mA residual current circuit breaker (RCCB) + protective circuit breakers (MCB).

230V 50Hz supply voltage

IP65 waterproof enclosure - IK08 impact resistance

Durable transparent door for quick and permanent viewing of your installation.
Possibility of putting lock. Cabled electrical box for simple and immediate connection.
UV-resistant product.

Voltage (in V) : 230V - 50Hz

Power (in W) : 3500W

Protection grade : IP65

Dimensions (in mm) : 420 x 330 x 160 mm

Colour : Light grey and black door

Type of lock : The door can be locked by 1/4  turn screws, and the box is screwed shut. Sealable door.

Composition : 16A 2P+T sockets, 40A AC-type RCCB, 16A single-phase MCB, emergency button and cable gland.

More info : Optional adaptable foot/support

Cables : Power cable not included

Type of installation : Surface, wall-mounting

Type of connection : Screw-type

Reference standard : EN 61439-1:2011; EN 61439-4:2013

Guarantee : 2 years
