Input voltage: 200~240V AC 50/60Hz
Material： aluminium body + PC diffuser
High grade aluminium, with white powder coated finish.
Length: 600mm & 1200mm
Wattage: 20W & 40W
Power factor: 0.95
Efficacy (lm/W)：80LM/W
Lumens：WW: 3200lm, CW: 3300lm
Lamp: SMD 2835 LED
CCT changeable:3000K–4000K–6500K Tri colour in one Light
CRI：>83
Beam angle：100 degree
Dimmable：No
Life time: 35,000hrs
SAA approved LED driver and Terminal block
Ambient temp: -20 to +40°C
MAX. Ta (Safety):50 degrees Celsius
Installation：Surface Mounted
IP Rating：IP20 indoor only

Shape Color: Black or White
Input Voltage: 200-240VAC
Product size: L420*120*190H mm
Globe: E27 PAR38 LED 10W
Lumens: 850lm WW 900lm CW each globe
CCT: 3000K / 4200K / 5000K/ 6500K
Material: ABS+PC
Installation: Surface mounted ( Inc. Wall mounting screws)
Protection: Class II
IP Rating: IP44 (Inc. 2PCS Waterproof seal)
Warranty: 2 Years

Specification of Sensor
Detection angle: 180°
Detection range: 12m
Duration Time: 5Sec-7Mins ±2mins
Manual Override: YES
Adjustable lighting modes
Sens-Adjust the PIR Sensitivity
Time:-Setting lighting time from 5Sec -7Mins When PIR is activated .
Lux: PIR Can be set to Work during day or night only .
PIR Sensor adjustable UP-Down & Rotatable Degrees: 340°
Sensing Angle: 180°
Recommended mounted height is 2 to 2.5meters
Bring Safety to Your Home-LED Security lights can turn on automatically when the motion is detected, sensing light levels and motion with a range of 180 degrees and max 50 feet. This Security light is IP44

• Selectable colour temperature to suit the installation and room
• Isolated external SAA Dimmable LED driver with flex & plug.
• High efficiency COB LED technology for superior light output.
• High-grade aluminium construction with gimbal design.
• Fits both 70 and 93mm cutouts and ideal for retro-fit applications.
• White / Black / Brushed Nickel / Sliver powder coated finish.

Item No.: DL1137
Product size: Dia. 100mm H85mm
Cut out size:70-93mm
Input Voltage：AC200-240V 50Hz
Rated Power：10W
LED: COB LED
CRI: 80
Beam angle: 50 °
Fitting Materials: Aluminium body +PMMA Lens
Fitting color:White / Black / Nickel / Silver
LUMENS:850-900Lumen
CCT（K）3000K -4200K -6500K Selectable
PF:0.80
Power supply:Isolated external driver
Dimmable
Lifespan @Ta 25°:40,000hrs*
IP Rating:IP20

Shape Color : White/Black
Product size(mm）Dia 111*66mm
Power（W）:15W
Input Voltage (V) AC 85-265V 50/60Hz
Efficacy (lm/W) : 90lm/w
LUMENS: 1350lm
LAMP: COB LED
CCT（K）3000K -6500K
CRI:80
Base:G53 or GU10
Beam angle:24°/ 36°
Material: Aluminum
Working Temp.:-30°C ~ +50°C
IP Rating: IP20 Indoor only

Input voltage: 200~240V AC 50/60Hz
Material： aluminium body + PC diffuser
High grade aluminium, with white powder coated finish.
Length: 600mm & 1200mm
Wattage: 20W & 40W
Power factor: 0.95
Efficacy (lm/W)：80LM/W
Lumens：WW: 3200lm, CW: 3300lm
Lamp: SMD 2835 LED
CCT changeable:3000K–4000K–6500K Tri colour in one Light
CRI：>83
Beam angle：100 degree
Dimmable：No
Life time: 35,000hrs
SAA approved LED driver and Terminal block
Ambient temp: -20 to +40°C
MAX. Ta (Safety):50 degrees Celsius
Installation：Surface Mounted
IP Rating：IP20 indoor only

Shape Color: Black or White
Input Voltage: 200-240VAC
Product size: L420*120*190H mm
Globe: E27 PAR38 LED 10W
Lumens: 850lm WW 900lm CW each globe
CCT: 3000K / 4200K / 5000K/ 6500K
Material: ABS+PC
Installation: Surface mounted ( Inc. Wall mounting screws)
Protection: Class II
IP Rating: IP44 (Inc. 2PCS Waterproof seal)
Warranty: 2 Years

Specification of Sensor
Detection angle: 180°
Detection range: 12m
Duration Time: 5Sec-7Mins ±2mins
Manual Override: YES
Adjustable lighting modes
Sens-Adjust the PIR Sensitivity
Time:-Setting lighting time from 5Sec -7Mins When PIR is activated .
Lux: PIR Can be set to Work during day or night only .
PIR Sensor adjustable UP-Down & Rotatable Degrees: 340°
Sensing Angle: 180°
Recommended mounted height is 2 to 2.5meters
Bring Safety to Your Home-LED Security lights can turn on automatically when the motion is detected, sensing light levels and motion with a range of 180 degrees and max 50 feet. This Security light is IP44

• Selectable colour temperature to suit the installation and room
• Isolated external SAA Dimmable LED driver with flex & plug.
• High efficiency COB LED technology for superior light output.
• High-grade aluminium construction with gimbal design.
• Fits both 70 and 93mm cutouts and ideal for retro-fit applications.
• White / Black / Brushed Nickel / Sliver powder coated finish.

Item No.: DL1137
Product size: Dia. 100mm H85mm
Cut out size:70-93mm
Input Voltage：AC200-240V 50Hz
Rated Power：10W
LED: COB LED
CRI: 80
Beam angle: 50 °
Fitting Materials: Aluminium body +PMMA Lens
Fitting color:White / Black / Nickel / Silver
LUMENS:850-900Lumen
CCT（K）3000K -4200K -6500K Selectable
PF:0.80
Power supply:Isolated external driver
Dimmable
Lifespan @Ta 25°:40,000hrs*
IP Rating:IP20
