With the Internet of Things (IoT) and the development of sensor technology, more and more devices are becoming IP enabled and connecting to the copper horizontal cabling infrastructure. Most of these devices such as IP security cameras, building automation controls, and Wi-Fi access points include an integrated RJ45 port for connecting to the network. These are resulted in the practice of installing Direct Connect links using Field Termination Plugs or PoE compliant patch cord connect directly to devices. TIA standards will call this topology “Modular Plug Terminated Link” or MPTL in TIA-568.2-D, which should be available late in 2018.

Before, installers used regular Cat,6 and Cat.6A modular plugs to terminate horizontal cabling. This termination is not easy, time consuming, yields unpredictable performance results. Also, these plugs do not accommodate the larger conductors utilized in 22 or 23AWG cabling. The increasing data rates of wireless access points and other devices require a 500Mhz or higher cabling link with DC power to support fast Power over Ethernet, field termination plug, or JE’s patch cord is the most perfect and practical solution. Both of shielded (die-casting) and unshielded systems, JE is ready to serve these two Direct Connect deployments.

Design advantage:

* Easy and quick to terminate with cables

* Guaranteed stable and excellent performance (Cat.8 is approved by GHMT)

* PoE ++ compliant

* Accommodated to 22AWG ~ 26AWG

* Repeatable installation

Application:

* Direct Connect to IP cameras

* Direct Connect to WAPs

* Direct Connect to Access Controls

* Direct Connect to Facial Recognition Systems

* Direct Connect to Building Management Systems

Specifications

* Cat.6A & Cat.8 available

* Shielded (Die-Casting) & UTP

* Toolfree

* 22~26AWG (solid & stranded)

JE supports one diversified copper solution in any environment. Component-rated connectors, patch panels and patch leads support application in data center, from computer clusters to server row or other demanding application.

Increasingly higher-bandwidth requirements continue to drive development and demand for 10G and 40G systems. Example consumer applications include YouTube, Facebook, smart phones and IP-TV. Governmental and business demands compound the urgency with a variety of complex data intensive solutions including weather prediction, financial analysis, genomics research, and design simulation. Further, the rapid emergence of cloud computing for both personal and business use adds additional challenges for high-volume, high complexity data transmission. JE’s Cat.6A and Cat.8 solution are the ones, supporting a superior performing network and next generation advance.

Design advantage:

* Low initial cost

* The ability to deliver higher data rate LAN services

* The flexibility to use one medium for all services

* Cat.8 channel is approved by GHMT, Cat.6A is approved by GHMT PVP

Specification

* Die-Casting connector for shielded solution

* High density patch panel (0.5U 24port /1U 48 port) is available

* Solid & Stranded patch cord available for both Cat.6A and Cat.8

Features

• Available for 8F, 12F, 16F, 24F and 32F in one MTP®/MPO connector interface.
• Support polarity method A, B, C and customized polarity methods; option for male (with pins) and female.
• Options with BIMMF OM3, OM4, OM5 and BISMF OS2 G.657.A.
• “Plug and Play” solution eliminates in-field termination, reduces installation cost and time.
• 100% factory terminated and tested to ensure superior performance and quality.
• 8, 12, 24, 36, 48 cores… up to 288 cores are available in trunk cables.
• Parallel optical transmission over 40G / 100G / 400G / 800G Ethernet.

Products

• Array Cord and Trunk Cable
• QSFP+ Conversion Cables (Y Cables)
• 1 to 2 Splitter
• Lookback
• Armored Patch Cord
• ODVA Series

Applications

Communication networks

Data center infrastructure

Fiber channel for storage area network
