ISOLATORS-PV is a complete range of switch-disconnectors with thermoplastic enclosure and an exclusively black knob.

They are used in photovoltaic applications, where the IEC 60364-7-712 standard prescribes the need to isolate the photovoltaic panel from the rest of the system.

This is made possible by disconnectors that operatein DC current, thus ensuring higher performance than those in AC alternating current.

OPTIMA-EX[GD] is a range of switched interlocked connectors from 16 to 32A for applications in Zone 1/2 (Gas) and 21/22 (Dust).
The enclosure, made of dissipative thermoplastic material reinforced with glass fiber, is resistant to impact even at low temperatures and its design eases the wiring operations as well as use.
The mobile interlocked socket outlets of OPTIMA-EX[GD] Series are equipped with a non-sparking Ex switch.

BE-D is a range of wall boxes for electric vehicles recharging in DC direct current at 25kW, equipped with one or two cables with a CCS2 or CHAdeMO connector, to be positioned on specific surface mounting holders when not in use.
The user interface is guaranteed by a touch screen display. BE-D charging stations, equipped with Ethernet-WiFi-2/3/4G connectivity, can be managed through Scame Management System or
can be connected to an OCPP backend.
Made of halogen-free technopolymer and embellished with a powder-coated aluminium frame, they are characterized by clean and essential lines, signed by Trussardi+Belloni Design, which make them
the ideal choice in any context. A specific pedestal in powder-coated steel allows BE-D charging stations floor mounting.

PROXIMA is a complete range of interlocked socket outlets from 16 to 63A, with or without fuse protection in 16A and 32A versions.
Available as single surface mounting or flush mounting socket outlets to be installed on the relative modular bases and distribution assemblies system.
Flush mounting versions have the switch pre-wired upstream to speed up the wiring operations of the distribution assemblies.
The large and recessed knob facilitates operation in any condition, while at the same time preventing breakage from accidental impacts.
The socket cover has a clear indication of the open and closed positions and is equipped with a high grip ring nut to ease tightening operations.

ISOLATORS-PV is a complete range of switch-disconnectors with thermoplastic enclosure and an exclusively black knob.

They are used in photovoltaic applications, where the IEC 60364-7-712 standard prescribes the need to isolate the photovoltaic panel from the rest of the system.

This is made possible by disconnectors that operatein DC current, thus ensuring higher performance than those in AC alternating current.

OPTIMA-EX[GD] is a range of switched interlocked connectors from 16 to 32A for applications in Zone 1/2 (Gas) and 21/22 (Dust).
The enclosure, made of dissipative thermoplastic material reinforced with glass fiber, is resistant to impact even at low temperatures and its design eases the wiring operations as well as use.
The mobile interlocked socket outlets of OPTIMA-EX[GD] Series are equipped with a non-sparking Ex switch.

BE-D is a range of wall boxes for electric vehicles recharging in DC direct current at 25kW, equipped with one or two cables with a CCS2 or CHAdeMO connector, to be positioned on specific surface mounting holders when not in use.
The user interface is guaranteed by a touch screen display. BE-D charging stations, equipped with Ethernet-WiFi-2/3/4G connectivity, can be managed through Scame Management System or
can be connected to an OCPP backend.
Made of halogen-free technopolymer and embellished with a powder-coated aluminium frame, they are characterized by clean and essential lines, signed by Trussardi+Belloni Design, which make them
the ideal choice in any context. A specific pedestal in powder-coated steel allows BE-D charging stations floor mounting.
