No.of pole: 1P+N, 3P+N
Rated voltage: 240/415V AC
Rated current:16-63A
Rated frequency: 50/60Hz
Rated short-circuit current: 6000A
Time delay: general type or type S
Operating characteristic: AC and A type
Rated residual operating current: 10,30,100,300mA
Comply with IEC/EN61008-1, IEC/EN61008-2-1

No.of pole: 3P, 4P
Rated voltage:250V/ 400V AC
Rated current: 50/60Hz
Control circuit voltage:24V/110V/230V
Rated insulation voltage: 500V
Rated impulse withstand voltage: 4kV
Utilization category: AC-7a/ AC-7b
Comply with IEC/EN61095

No.of pole: 1P , 2P ,2+1P , 3P , 3+1P ,4P
Rated voltage: 275V , 320V , 385V ,440V AC
500V , 600V , 800V ,1000V DC
Maxium discharge surge current: 10 kA , 20kA ,40kA , 60kA ,80kA ,100kA
Type of network systems: TN-S, TN-C-S , IT , TT , PV
Plug-in replacement module with indicator
Available with signaling auxiliary
DIN rail 35mm installation
Comply with IEC61643-11, EN50539-11

No.of pole: 1P,2P,3P,4P
Rated voltage: 240V/415V AC
Rated current: 1-63A
Rated frequency: 50/60Hz
Tripping curve: B,C,D
Rated insulation voltage: 415V
Rated impulse withstand voltage: 4kV
Rated short-circuit breaking capacity: 6000A
Comply with IEC60898-1

No.of pole: 1P+N, 3P+N
Rated voltage: 240/415V AC
Rated current:16-63A
Rated frequency: 50/60Hz
Rated short-circuit current: 6000A
Time delay: general type or type S
Operating characteristic: AC and A type
Rated residual operating current: 10,30,100,300mA
Comply with IEC/EN61008-1, IEC/EN61008-2-1

No.of pole: 3P, 4P
Rated voltage:250V/ 400V AC
Rated current: 50/60Hz
Control circuit voltage:24V/110V/230V
Rated insulation voltage: 500V
Rated impulse withstand voltage: 4kV
Utilization category: AC-7a/ AC-7b
Comply with IEC/EN61095

No.of pole: 1P , 2P ,2+1P , 3P , 3+1P ,4P
Rated voltage: 275V , 320V , 385V ,440V AC
500V , 600V , 800V ,1000V DC
Maxium discharge surge current: 10 kA , 20kA ,40kA , 60kA ,80kA ,100kA
Type of network systems: TN-S, TN-C-S , IT , TT , PV
Plug-in replacement module with indicator
Available with signaling auxiliary
DIN rail 35mm installation
Comply with IEC61643-11, EN50539-11
