THE USE OF RED COPPER CONDUCTOR, STRONG CORROSION RESISTANCE, STRONG TIGHTNESS IT IS NOT EASY TO RELAX AND FALL OFF, WITH GOOD CONDUCTIVITY AND CHEMICAL STABILITY AND NO RISK OF FRACTURE OF PRESSURE CORROSION

PCB terminal block is an important connector of the input and output of PCB electric current and signal.It is a kind of terminal withe the most structures,types and the widest applications among all the European-style terminal blocks.It is mainly used in some industries such as industrial control, communication, electric power,security and protection, and monitoring.According to the product and wire connecting structure characteristics, UTL divides this model into 4 types including lifting cylinder type, cam type, wire-protecting type and spring type.Through combining its own connecting grooves(connecting holes)with other 2-hole or 3-hole products, the specifications ranging from 2 holes to 24 holes or even more holes can bereached so as to meet the require-ments of different wire connecting quantity(part of products apply the one-piece-no-connecting structure).

Suitable for the connection of 0.2-4mm solid wire or stranded wire.
For solid wire, it could be inserted directly without opening the hand lever for stranded wire, please use screwdriver or electroprobe to open the hand lever first, then to insert the wire and push back the hand lever.

• Terminal with universal mounting foot can conveniently and quickly installed in the U type guide rail NS35 and G type guide rail NS32;
• Screw closed guide hole is convenient screwdriver operation, and can prevent the screw loosening after dropping machine;
• Potential distribution by an access terminal central center contact piece or inserted into a conical connecting hole edge inserted contact element to realize;
Terminal for a plurality of section is equipped with universal accessories, such as: end plate, separating plate, septa etc.;
• Insulated shell of high mechanical strength, good electrical properties, imported engineering plastics extremely flexible spear amides adopt (nylon) 66;
• The top two end with white markings Celje, can realize the unified logo.

THE USE OF RED COPPER CONDUCTOR, STRONG CORROSION RESISTANCE, STRONG TIGHTNESS IT IS NOT EASY TO RELAX AND FALL OFF, WITH GOOD CONDUCTIVITY AND CHEMICAL STABILITY AND NO RISK OF FRACTURE OF PRESSURE CORROSION

PCB terminal block is an important connector of the input and output of PCB electric current and signal.It is a kind of terminal withe the most structures,types and the widest applications among all the European-style terminal blocks.It is mainly used in some industries such as industrial control, communication, electric power,security and protection, and monitoring.According to the product and wire connecting structure characteristics, UTL divides this model into 4 types including lifting cylinder type, cam type, wire-protecting type and spring type.Through combining its own connecting grooves(connecting holes)with other 2-hole or 3-hole products, the specifications ranging from 2 holes to 24 holes or even more holes can bereached so as to meet the require-ments of different wire connecting quantity(part of products apply the one-piece-no-connecting structure).

Suitable for the connection of 0.2-4mm solid wire or stranded wire.
For solid wire, it could be inserted directly without opening the hand lever for stranded wire, please use screwdriver or electroprobe to open the hand lever first, then to insert the wire and push back the hand lever.
