This new Fluke thermal camera stays true to our mantra of giving the customer more than they paid for. The Fluke TiS75+ offers features to help you tackle almost anything you’ll face in the field.

• 384 x 288 infrared resolution
• Asset Tagging
• Touchscreen IR Fusion™
• IS3 and AVI video recording
• Measure up to 550 °C
• Dew-point calculation
• IS3 and AVI video recording
• Data streaming
• 384 x 288 thermal resolution
• High temperature range—up to 550 °C
• Dew-point calculation

The 279 FC multimeter is a full-featured multimeter with built-in thermal imager that reveals hot spots that may indicate electrical issues quickly and safely.

• Safer and rugged: Safety rated CAT III 1000 V, CAT IV 600 V
• Save time: With built-in Fluke Connect®, transmit results wirelessly to a smartphone
• Flexibility: Compatible with iFlex® to expand your measurement capabilities and get into tight, hard to reach spaces for current measurement
• Accurate results: Full-featured multimeter with built-in thermal imager
• True-RMS AC voltage and current for measuring non-linear signals

How fast will you find your first leak?

Right out of the box, the Fluke ii900 is ready to use. It’s rugged and ergonomic design make it easy to handle and the large 7” LCD display make leaks easy to see. Within minutes, a user with little-to-no experience can start detecting leaks. When the Fluke engineers were considering the users of the ii900, they wanted to make sure all the necessary components were built-in and easy to access. In addition, the Fluke engineers knew shutting down the plant or putting technicians in harm’s way was out of the question—that’s why they made sure the Fluke ii900 Industrial Acoustic Imager could be used in noisy environments and from a safe distance.

• Do more with the same air compressors – delay the capital expense of purchasing an additional compressor
• Ensure proper air pressure to your pneumatic equipment
• Lower utility costs
• Reduce leak detection time
• Improve reliability in your production line
• LeakQ Report Generator

Test the safety and functionality of electrical vehicle charging stations, easily and reliably
The FEV300 Test Adapter Kits are designed to test function and safety of charging stations mode 3 for AC charging. The adapter imitates an electric vehicle and opens up a charging cycle (activating voltage/current output), allowing you to conduct tests in combination with appropriate test instruments like an installation tester (for example the Fluke 1664 FC) and/or an oscilloscope (for example the Fluke 120B Series Industrial ScopeMeter®). With the FEV300 Adapter Kit, charging stations can be tested in accordance with IEC/EN 61851-1 and IEC/HD 60364-7-722.

Fluke 393 Solar Clamp Meter CAT III 1500 V

The 393 FC CAT III 1500 V True-rms Clamp Meter with iFlex is designed for solar photovoltaic (PV) installation technicians and maintenance professionals who work in high voltage dc environments: PV arrays, wind power, electric railways, data centers battery banks for uninterruptible power supplies. The clamp will measure up to 1500 V dc, 1000 V ac, and up to 999.9 A dc or ac through the clamp jaw. The included iFlex flexible current probe extended ac current measurements up to 2500 amps. This clamp has a thin jaw, giving you access to cables in crowded combiner boxes. Test leads are designed with your work in mind, and are also rated to CAT III 1500 V dc.

Key functions of the solar clamp meter:

• IP54 rated, ideal for work outdoors including PV panel testing
• DC power measurement, showing readings in kVA
• Audio Polarity indicator helps prevent accidental miswires
• Visual Continuity turns provide a bright green light in the display, ideal when working in dark and noisy environments
• Logging and reporting of test results via Fluke Connect software
• When measuring ac current the included iFlex flexible current probe gives you unparalleled access to cable is tight spaces. The iFlex probe can be twisted through extremely small spaces and provide accurate current measurements.
