wscaduniverse.com is the biggest electrical CAD data repository in the world. Use current and reliable part data for over 2.1 million parts from more than 400 manufacturers in the formats WSCAD, 3D-STEP, DWG and EDZ. Increase the quality of your work results and save valuable time. wscaduniverse.com is totally free of charge!

Simply start through your browser or directly from our WSCAD application and then search, find, select and insert the parts into your own WSCAD and EDZ or DWG projects. Or easily use 3D STEP data for the Cabinet Engineering in the WSCAD software.

As a manufacturer you can benefit from the unique global reach of wscaduniverse.com: your products can be directly used in the engineering projects of approx. 135,000 users of professional electrical CAD solutions. This adds value in the engineering processes of both your potential customers and your company. In short: the perfect way to start a new business relationship. The upload and provisioning of parts data is free of charge.

Your advantages at a glance:

• Download of over 2.1 million parts – now also available in DWG
• It is no longer necessary to draw the items, this applies to circuit diagram and control cabinet structure
• Free registration and download
• Symbol creation of further parts on request

Maintainer and service technicians can scan individual cabinet components with the WSCAD Cabinet AR App and immediately receive information about the component as well as its position in the electrical plans.

The modular WSCAD software supports engineering with many functions for standard-compliant documentation. Modern 3D technology and augmented reality (AR) enable interactive work in control cabinet construction, installation technology and building automation.

The WSCAD Cabinet AR app allows you to retrieve information about the schematics and components of a cabinet using your tablet or smartphone. The documentation is available completely and in accordance with the standards in the form of intelligent PDFs with cross-references. A special viewer tool is not required. The technician or maintainer on site can immediately switch from the control cabinet to other schematic thanks to the app.

With the camera of your mobile device, you scan the WSCAD QR codes that are attached to the components. The app recognizes the scanned component, displays it in the schematic and shows all technical data and comments. Maintenance staff have all information immediately available without searching in the documentation. Using the label function of the WSCAD software, you can generate the QR codes quickly and easily.

The engineer on site can use the app to immediately note changes and comments in the PDF with the new redline function. These correction notes are added to the schematics and, after export to cloud storage, are available to all those involved for further editing in the WSCAD software.

In addition, you can mark connections (wires) that you have already wired in the control cabinet in the wiring list. This gives you a clean overview of connections that are still missing.

Functions of the WSCAD Cabinet AR App at a glance:

• Display information of the components
  (reference name, function text, part number, manufacturer)
• Interactive 3D models of the components
• Call up data sheet
• Display schematics
• Add changes and comments immediately recognisable in the schematics (via redline function) and make them available to all participants
• Call up wiring information of the control cabinet
  (target 1, target 2, potential, wire cross-section, wire color code)
• Mark wired connections
• Export changes back to the cloud for further editing

The Cabinet AR App is compatible with WSCAD ELECTRIX. It can be downloaded free of charge for smart phone and tablet from the Apple App Store* (iOS operating system) and Google Play* (Android operating system).

* Brand names, logos and trademarks used herein remain the property of their respective owners. The listing of any firm or their logos is not intended to imply any endorsement or direct affiliation with WSCAD GmbH.

With the WSCAD Building AR App you can create a building plan using your mobile device (tablet or smartphone) and then import it into the WSCAD schematics as a background. To do this, simply scan the rooms of the building with the camera of your mobile device and combine the rooms and floors into a plan as a DXF or PDF. It can be downloaded for free from the Apple App Store for the iOS operating system. The Building AR App for the Android operating system is unfortunately not yet available, but is already being created.

Functions of the Building AR App:

• Download and start the Building AR App
• Create/open project
• Capture room
• Add windows and doors
• Structure rooms
• View/edit plan
• Export plan
• Import plan into the WSCAD software

Our latest E-CAD software, ELECTRIX ROCKET, is specially designed for applications in building automation, mechanical and plant engineering, installation technology and control cabinet construction. It integrates the specialist areas of building automation, electrical engineering, electrical installation, control cabinet design as well as fluid technology and piping and instrument diagrams in a single software solution. Compared to the previous version, WSCAD SUITE X PLUS, ELECTRIX ROCKET impresses with up to 100% higher performance. The improvements include a completely newly developed design engine (editor) and built-in compatibility with the standard CAD formats DXF/DWG. Graphical operations are significantly accelerated by ELECTRIX ROCKET's full utilization of your graphics card (GPU). ELECTRIX ROCKET also uses advanced technologies such as augmented reality, multi-threading and automation to make operation even more intuitive and provide numerous functions that make your daily electrical engineering tasks easier.
ELECTRIX ROCKET offers a wide range of new features, including the improved "Search & Click" quick search, greatly improved performance, a newly developed search function in the material and project explorer, new tooltip functions in the article management, a transparent 3D view of the control cabinet, real-time scaling of P&ID symbols, as well as a drawing area five times larger than the selected sheet format and direct size input with automatic snap points.
Further information: https://www.wscad.com/en/electrix
