Detection, localisation and people counting - without a camera.

What does EO know?

Where people are located
How long people have been there
How many people are in the room
Which entrances and exits are being used
What is the temperature of people
What is the temperature in certain zones

• Easy to mount due to magnetic holder and round design
• Presence detector with 8 m motion detection and 6 m presence detection for switching light
• Ideal for large offices, meeting rooms or passageways
• Push-button input and parallel connection of up to 10 sensors for range extension
• Including pluggable cover caps for detection limitation
• External approval and measurement according to sensNORM

• Easy to mount due to magnetic holder and round design
• Presence detector with 24 m motion detection and 7.5 m presence detection for integration into a KNX bus system
• Ideal for large offices, meeting rooms or passageways
• Starting the programming mode from a distance via Smart Remote remote control via app
• Including pluggable cover caps for detection limitation
• External approval and measurement according to sensNORM

Small. Slim. Compact. Inconspicuous presence detectors. 360° passive infrared sensor with a presence detection zone of 4 x 4m (presence and radial movement detection) or 6 x 6m (tangential movement detection). With patented fresnel lens.

The PIR NET is part of the innovative SENSOTEC NET wireless Mesh product family, which can be networked wirelessly via a Bluetooth Mesh network, can be configured via an app and controls LED drivers via the DALI bus.

The PIR NET is also available as an IPD sensor. The IPD sensors are a version of the NET sensor product family reduced to the sensor advantages, function as standardised DALI-2 input devices and have no wireless networking.

A head for heights. Powerful reach. Reliable. Ideal for high ceilings in industrial buildings or commercial properties. For mounting heights of up to 14m. High-precision 360° infrared sensor. Maximum detection range diameter 36m. For watching over up to 1000sqm.

The HB PIR 3360 NET is part of the innovative SENSOTEC NET wireless mesh product family, which can be networked wirelessly via a Bluetooth mesh network, can be configured via app and controls LED drivers via the DALI bus.

The Highbay sensors are available in three connection variants. As an intra version for luminaire installation, with Zhaga base (screw ring) and as a wire version (strands for wiring) for luminaire installation.

The HB PIR 3360 is also available as an IPD sensor. The IPD sensors are a version of the NET sensor product family reduced to the sensor advantages, function as standardised DALI-2 input devices and have no wireless networking.

Detection, localisation and people counting - without a camera.

What does EO know?

Where people are located
How long people have been there
How many people are in the room
Which entrances and exits are being used
What is the temperature of people
What is the temperature in certain zones

• Easy to mount due to magnetic holder and round design
• Presence detector with 8 m motion detection and 6 m presence detection for switching light
• Ideal for large offices, meeting rooms or passageways
• Push-button input and parallel connection of up to 10 sensors for range extension
• Including pluggable cover caps for detection limitation
• External approval and measurement according to sensNORM

• Easy to mount due to magnetic holder and round design
• Presence detector with 24 m motion detection and 7.5 m presence detection for integration into a KNX bus system
• Ideal for large offices, meeting rooms or passageways
• Starting the programming mode from a distance via Smart Remote remote control via app
• Including pluggable cover caps for detection limitation
• External approval and measurement according to sensNORM
