True alternative to HPS contributing to the realization of a sustainable society

An HPS color LED is an LED that genuinely reproduces the emission color of High Pressure Sodium lamps (HPS), which is most often used for road lighting and outdoor lighting around the world. As a true alternative technology to mercury-containing HPS, it will contribute to the realization of a mercury-free society and carbon neutrality.

In street and outdoor lighting, the use of LEDs has been increasing over the past decade or so due to their high efficiency and long life; however, in residential areas and the center of town, there are cases where the switch to LEDs is not being made because there is a concern that the bluish white light of LEDs may change the familiar landscape and atmosphere.

In some extreme cases, street lights that were once converted to LED have been changed back to HPS due to demands from residents. In addition, attention has been drawn to so-called "light pollution", such as sleep disturbance due to excessive glare, inability to see the stars because of the dim night skies, and adverse effects not only on humans but also on the ecosystem including insects.

Nichia's HPS color LEDs can significantly change this situation. While they have the same emission color delivered by HPS, HPS color LEDs would not change the landscape and atmosphere. In addition, it reduces the light pollution caused by the higher CCT LEDs. Thus, it can be expected to accelerate the smooth shift to LEDs in cases where the switch to LEDs have not progressed due to the emission color.

High luminous flux density chip scale LED

The Direct Mountable Chip is a chip scale LED which has been developed through Nichia's technology and expertise in phosphors and LEDs. The white series has four size options (1.1mm×1.1mm, 1.3mm×1.3mm, 1.7mm×1.7mm, and 2.1mm×2.1mm) with color temperatures ranging from 1800K to 6500K, and color rendering index options from R70 (Ra≥70) to R9080 (Ra≥90, R9≥80).

The color series offers a wide variety of discrete colors in two size options (1.1mm×1.1mm in three colors and 1.7mm×1.7mm in eight colors) with the same forward voltage for each size to allow for easier fixture design.

By making the LED package size equal to the light emitting surface size, it is possible to achieve the largest class of luminous flux density in a limited space within a luminaire.

What can be achieved with the Direct Mountable Chip?

• High luminous flux density enabling compact fixture design.
• A wide variety of power output options to support various applications.
• Compact light emission size provides optimal color mixing and this enables customers to design tunable and/or multi-color fixtures easily.
• Uniformed forward voltage in all colors makes electrical control easier.

Ultra-wide light distribution LED module that realizes lighting spaces filled with soft light

Nichia Light Cluster™ Type L is a lighting LED module featuring ultra-wide light distribution, developed by combining the LED and optical technologies that Nichia has cultivated over many years, that enables designs of luminaires with uniform light emission, that are also thinner and lightweight.

In addition, the ultra-wide light distribution creates a soft light that envelops the entire space. With these unique features, this product brings new possibilities to the design of lighting fixtures and adds new value to lighting by saving resources and improving safety in buildings by reducing the weight of the fixture and ceiling.

Cube Direct Mountable Chip is an LED that realizes a horizontal light distribution by combining Nichia's expertise and technology in phosphors and LEDs cultivated over many years.

It can be freely arranged to match the design of the lighting fixture.

The combination of the energizing azure (sky blue) and a peaceful, calming warm white hue

Recently, the influence of natural light on the human body and its influence has been drawing attention, and its importance has been reaffirmed. It is believed that the insomnia and other physical disorders that a large number of people suffer from today can be attributed to modern lifestyles that make it difficult to get enough natural light. The building industry is increasingly encouraging designs that bring more natural light indoors. In the field of lighting, another major challenge is how to realize light and lighting environments that are comfortable for humans and therefore, so-called human centric lighting and circadian lighting have been gaining attention. There is a movement to require designs for indoor lighting with a new concept that focuses on the “quality of light” and the “function of light”.

What has been lacking in conventional indoor lighting is 480nm light, which is abundant in the morning sun. This 480nm light stimulates the secretion of serotonin, the “happy hormone,” and activates the human body and mind. The more serotonin secreted in the morning, the more melatonin, a sleep hormone, is secreted 14 to 16 hours later, using it as a source. Thus, 480nm light is considered as very important by having a twofold significance.
Focusing on this 480nm light, Nichia proposes Azure color LEDs that can effectively supply the light of that wavelength, and Dynasolis™, a color and spectrum tuning solution that is achieved by using Azure color LEDs.

Conventional color tuning lighting has used mainly 6500K LEDs on the high CCT side and 2700K LEDs on the low CCT side. Dynasolis™, which has the high CCT side replaced with Azure LEDs, can maximize the melanopic illuminance by increasing the output at 480nm, thereby stimulating physical and mental activation from awakening in the morning and melatonin secretion in the evening and beyond. Furthermore, by gradually reducing Azure-colored light and changing to the lower CCT, it is possible to produce light that gives a sense of comfort. Nichia approaches the adjustment of circadian rhythms from the perspective of spectrum tuning.
