Cupower - Shenzhen Xiezhen Electronics Co., Ltd.

Bluetooth driver platform

Trade fair innovation

Bluetooth driver platform

Cupower - Shenzhen Xiezhen Electronics Co., Ltd.
Supplier profileAll products
Contact supplierContact persons

Description

Bluetooth platform approach:

  • Multiple chips can be integrated and different systems (software) can be implemented
  • Easy switch to different systems
  • Only one thermal and EMC meassurement per platform: no need for separate meassurements using different systems

Technical highlights:

  • High antenna range due to special design
  • Build-in, independent with looping function, SELV, Non-SELV driver versions available
  • CUPOWER app for iOS and Android
  • NFC feature setting: Output current, CLO, DC-level, minimum dimming level

More from us

Our websiteOur product

Downloads

More products by Cupower - Shenzhen Xiezhen Electronics Co., Ltd.

Trade fair innovation

Non-SELV Industry series (ON/OFF and DALI)

(1) Non-SELV Industry DALI Series

Features

  • Constant power output designs with wide operating window
  • Supports DALI-2 and PUSH DIM
  • Supports i-Data function (DALI part 251, 252, 253, luminaire data, energy reporting, diagnostic and maintenance).
  • Supports NFC reader to precisely control current, CLO, dimming curve, DALI address, etc.
  • The DC emergency mode adjusts the current to 15% by default (adjustable)
  • Smooth dimming, flicker-free, dimming range 1-100% (amplitude dimming)
  • Standby power consumption < 0.3 W, meets ErP energy efficiency certification
  • High surge protection L-N: 4 kV，L/N-GND: 4 kV

(2) Non-SELV Industry NFC Series

Features

  • Constant power output designs with wide operating window
  • High power factor, suitable for Class I luminaires
  • Flicker-free
  • Supports NFC reader to precisely control current, CLO
  • High surge protection L-N: 4 kV, L/N-GND: 4 kV
Trade fair innovation

ID series - compact DALI drivers

Features

  • Constant power output designs with wide operating window
  • Supports DALI-2 and PUSH DIM and push CCT adjustable
  • Supports NFC reader to precisely control current, CLO, dimming curve, DALI address, etc.
  • Supports two independent DT6 or one DT8 output, dimming range 1-100% (amplitude dimming)
  • Smooth dimming and color temperature, flicker-free.
  • Supports i-Data function (DALI part 251, 252, 253, luminaire data, energy reporting, diagnostic and maintenance)
  • The DC emergency mode adjusts the current to 15% by default (adjustable), which is suitable for 30 W, 44 W, 60 W
  • Removable cord grips, comply with 2.5 mm2 engineering incoming line specification, cord grips for flat types only offer compatibility with 1.5mm2.
  • Standby power consumption < 0.3 W (30-60 W), 20 W < 0.5 W, meets ErP energy efficiency certification
