Solutions for the hotel industry
Ekinex has designed a complete range of products for the management and control of functions in a hotel room to which can be added the devices of the Ekinex catalogue, depending on the functions to be implemented.
The Ekinex EK-HO1-TP module allows the management of room functions: lighting, temperature control, shading and input and output signals.
The device is equipped with membrane buttons for manual control and LEDs for status indication; a button allows switching between automatic and manual operation.
The device has an integrated KNX bus communication module and is designed for mounting on a 35 mm profile rail. Power is supplied via the KNX bus; it requires an additional 230 Vac mains voltage for operation.
The card reader and the card holder are made with modularity equal to 2 modules in Italian standard (44 x 44 mm WxH). They can be installed on a square flush-mounting box (2 places) or on a round flush-mounting box with 60 mm fixing hole spacing. The power supply is 12-24 V AC/DC.
Both have a 4A to 24V relay output and a freely programmable binary input.
The output can be used for load control, while the binary input allows the connection of devices such as bathroom alarm rods or door and window open/close contacts.
