VIARIS

Dims light from 10% to 100% for concealed mounting in electrical installation box.

Fast installation and requires no work or neutral connection.

Valid for LED lamps up to 100 VA and halogen or incandescent lamps up to 150 W.

Reduced size for fitting between a pushbutton and the mechanism box, or concealed in inspection boxes, suspended ceilings, etc.

Press and let go will switch lights On/Off. Press and hold will dim the lights to the required level.

Quick non-disruptive installation; no neutral connection required.

Memory function for desired switch on level.

Reduces lighting power consumption and increases lamp service life.

Compatible with all commercially available push buttons.

Suitable for 2-way switching installations.

Suitable for all dimmable lamps, except 12 V dc LEDs operating with electromagnetic transformers.

Includes overload, thermal and short-circuit protection.

Presence detector with especially large detection capacity: of 7 m height and

30 m diameter.

Continuous ambient lighting measuring.

Zero-crossing relay for LED loads up to 500 VA.

Great detection capacity: 7m high 10m diameter to 3.5m high 30m diameter

Surface-mounting on the ceiling through a plug-in base for faster installation.

Classified as a presence detector by its high detection capacity and because it is equipped to continuously measure ambient light levels.

Optionally it can be programmed using the remote control MANDO CR which allows the changing of parameters and functions without the need of a ladder or tools. It streamlines and simplifies both installation and maintenance.

Status LED: detects movement or changes in lighting conditions.

Stepless dimming timing.

Pulse function: 1 s ON / 4 s OFF.

Zero-crossing relay for a better switching of LED-type loads.

Adjustable parameters: detection area, timing, and light sensitivity.

Detection field limiter included.

Accesory: remote control

Modbus (RTU and S0) communication.

Wh and VArh import / export load curve, log file up to 12 months.

Recording of maximums, power failures and several electrical parameters.

Billing: 12 months, 4 rates, 6 daily periods and public holidays.

Digital single-phase power meter with internal memory and MODBU (RTU) communications.

Direct measurement 10 (60) A. Up to 6 daily periods with 4 possible tariffs.

Recording of import and export data for energy-generating installations, solar installations...

Upper limit register: V, A, Wh y VArh. Power cut register.

12 monthly closures: Wh import./export. y VArh import./export.

Load curve of V, A, Wh y VArh. It is configurable every 15, 30 and 60 minutes.

LCD display with the following instantaneous parameters: V, A, W, VAr, VA, cos Phi, Hz

Opto-isolated pulse output or RS485 communications.

10-year memory backup by lithium battery.

Accessories: USB-RS485 adapter (OB707022) and MODBUS/TCP gateway (OB709972).

Daily updating and easy programming guided by text menus.

Fixed or astronomical manoeuvres (sunrise and sunset).

With Bluetooth connection for smartphone programming.

4 annual periods for special programming.

Backlit display to improve viewing, even in the dark.

Power supply:230 ± 10 % Vac

Frequency:50 / 60 Hz

Switching capacity:16(10) A / 250 V ac

Degree of protection:IP20 according to EN 60529

DIN rail 2 modules

Operating temperature:-10 ºC to 45 ºC
