Spot LED Modules

Flexible Aluminum Ring LED Module with Uniform Light Distribution for Edge-lit Applications

Flexible LED Module with Aluminum Ring

• 193 ~ 505mm
• 2600 ~ 7000lm @ 1000mA, Tc=65◦C
• Module efficacy up to 130lm/W
• CRI of 90+
• Wire harness for easy wiring
• modular ring LED modules

LED modules with optics, engineered in multiple form factors for various applications

Square LED Module with Optic

• 115mm × 115mm
• 3700lm @ 1050mA, Tc=65◦C
• Module efficacy up to 101.2lm/W (with lens)
• CRI of 90+
• White light with integrated optics
• To be used with wire harness

Round LED Module with Optic

• 180mm × 180mm
• 3500lm @ 700mA, Tc=65◦C
• Module efficacy up to 114lm/W (with lens)
• CRI of 80+
• White light with integrated optics
• Re-workable push-in connectors for easy wiring

Linear LED Module with Optic

• 588mm × 20mm
• 1290lm @ 375mA, Tc=55◦C
• Module efficacy up to 156lm/W (with lens)
• CRI of 80+
• White light with integrated optics
• Re-workable push-in connectors for easy wiring

Round LED Modules with various color combination and performance to apply to diverse lighting system requirements.

Big Round LED Module

• 390mm × 390mm
• 4000lm @ 700mA, Tc=45◦C
• Module efficacy up to 133lm/W
• CRI of 90+
• To be used with wire harness

Round LED Module with lens

• 318mm × 318mm
• 2800lm @ 700mA, Tc=55◦C
• Module efficacy up to 154lm/W (with lens)
• CRI of 90+
• Re-workable push-in connectors for easy wiring
• 240ea LEDs and lenses

Linear LED Modules with various color combination and performance to apply to diverse lighting system requirements.

Tunable White & Color Linear LED Module

• 560mm × 38mm
• 1960 ~ 2200lm @ 600mA, Tc=55◦C
• Module efficacy up to 160lm/W
• CRI of 80+
• Tunable white and color with 3 independent channels
• Suitable for robot wiring

Single White & Color Linear LED Module

• 560mm × 24mm
• 360 ~ 2200lm @ 300mA, Tc = 55 °C
• Module efficacy up to 160lm/W
• CRI of 80+
• Single white and color with 2 independent channels
• Re-workable push-in connector for easy wiring

Linear LED Module with Integrated Driver

• 560mm × 24mm
• 1400lm @ 380mA, Tc=55 °C
• Module efficacy up to 158lm/W
• CRI of 80+
• On-board linear led driver for constant voltage driving
• Discrete Wire IDC(Insulation Displacement Connectors)
