MINI-1CV-CASAMBI

LINE-5CV-DMX is a 5-channel output LED dimmer, which can be controlled by means of a DMX BUS control.
The LED dimmer is suitable for driving loads such as StripLEDs and LED modules, White, Single-color, Dynamic White, RGB, RGB+W, RGB+WW and RGB+TW at constant voltage. A 12-24-48 Vdc power supply can be connected.
The maximum output current is 12A. The dimmerLED has the following protections: short-circuit protection on the LED outputs, over-power protection, reverse polarity protection, and input fuse protection.

RUNNING-LIGHT is an SPI controller for pixel-to-pixel LED control on digital (programmable/addressable) LED strips, which can be connected to a SELV constant voltage (5 ÷ 24) Vdc power supply. The controller is suitable for driving loads such as Digital LED-strips and RGB or WWW LED modules at constant voltage. It can be controlled locally via Normally Open (N.O.) pushbutton or remotely via DALI (Digital Addressable Lighting Interface) digital protocol.
RUNNING-LIGHT can deliver a maximum output current of 7 A and has the following protections: over-voltage and under-voltage protections, reverse polarity protection and input fuse protection.

PIXEL-TILE-300-RGBW-12V is an SPI pixel-to-pixel LED-module with N°100 digital (programmable/addressable) RGBW LEDs, which can be supplied by a SELV constant voltage 12 Vdc power supply. The LED-module is suitable to be driven by an SPI LED-controller at constant voltage.

MICRO-1CV is a 1-channel Pulse Width Modulation (PWM) Constant Voltage (CV) LED dimmer. It can be powered from a constant voltage (12 ÷ 48) Vdc SELV power supply and is suitable for driving a load such as Strip LED and White/Monochrome LED modules at constant voltage. The dimmer can be controlled via Normally Open (N.O.) push-button, analog input 0/1-10V, or via a 10 kΩ potentiometer; the automatic detection of the local control that ensures the proper functionality related to the type of the connected control.
MICRO-1CV can deliver a maximum output power up to 78 W (@12V) or 150 W (@24/48V) and has the following protections: over-voltage and under-voltage protections, reverse polarity protection, input fuse protection and open-circuit protection.
Through the Push Menu are possible to configure multiple parameters including dimming frequency, Fade In/Out time values and minimum brightness level.

LINE-5CV-DMX is a 5-channel output LED dimmer, which can be controlled by means of a DMX BUS control.
The LED dimmer is suitable for driving loads such as StripLEDs and LED modules, White, Single-color, Dynamic White, RGB, RGB+W, RGB+WW and RGB+TW at constant voltage. A 12-24-48 Vdc power supply can be connected.
The maximum output current is 12A. The dimmerLED has the following protections: short-circuit protection on the LED outputs, over-power protection, reverse polarity protection, and input fuse protection.

RUNNING-LIGHT is an SPI controller for pixel-to-pixel LED control on digital (programmable/addressable) LED strips, which can be connected to a SELV constant voltage (5 ÷ 24) Vdc power supply. The controller is suitable for driving loads such as Digital LED-strips and RGB or WWW LED modules at constant voltage. It can be controlled locally via Normally Open (N.O.) pushbutton or remotely via DALI (Digital Addressable Lighting Interface) digital protocol.
RUNNING-LIGHT can deliver a maximum output current of 7 A and has the following protections: over-voltage and under-voltage protections, reverse polarity protection and input fuse protection.

PIXEL-TILE-300-RGBW-12V is an SPI pixel-to-pixel LED-module with N°100 digital (programmable/addressable) RGBW LEDs, which can be supplied by a SELV constant voltage 12 Vdc power supply. The LED-module is suitable to be driven by an SPI LED-controller at constant voltage.
