Window drives of the GEZE IQ windowdrive series, such as the Slimchain and Powerchain chain drives, can be connected to the KNX building bus via IQ box KNX. Further components - such as heating or air conditioning - can also be integrated using KNX actuators. KNX sensors provide data regarding room air quality and outside environmental conditions. This ensures an optimum, energy-efficient indoor climate.

Slimchain - slim all-round talent

• Compact Slimchain chain drive for a discreet façade design
• Suitable for natural ventilation, smoke and heat extraction and natural SHEVs
• Different stroke variants of 300 mm, 500 mm and 800 mm
• Individually adjustable drive strokes and speeds
• Simple synchronisation of up to four drives, without external control device

Powerchain - real power package

• Powerchain chain drive for heavy façade windows and roof windows
• Suitable for natural ventilation, smoke and heat extraction and natural SHEVs
• High opening speeds and large opening widths in case of smoke and heat extraction
• Different stroke variants 600 mm, 800 mm and 1,200 mm
• Individually adjustable drive strokes and speeds
• Simple synchronisation of up to four drives, without external control device

Always open but safely closed - the demands on escape and rescue routes are extensive, and initially seem contradictory. They need to save lives in the event of danger, and prevent access by unauthorised persons on an everyday basis. Intelligent emergency exit system solutions are the perfect solution for this apparent contradiction.

With the GEZE emergency exit system, you not only secure your emergency exits against unauthorised access, ensuring EltVTR compliance; you also already meet the new standards in accordance with EN 13637.

Emergency exit systems are subject to strict legal requirements for both personal and property protection. Especially where people are not provided with instructions and are not familiar with the surroundings. GEZE offers solutions for securing escape doors that are matched to the specific requirements and individual emergency exit concepts - in healthcare, educational institutions, office and sales rooms.

The TZ 320 door control unit is the heart of the emergency exit system SecuLogic, and is used to control and monitor electrically-locked escape route doors with the aid of individual authorisations.

TZ 320 - our all-rounder:

• Can be used in simple emergency exit system applications
• Can be used with automatic swing door drives
• Can be used with motor locks
• Can be used with GEZE Cockpit and TE 220
• Can be used on bi-directional emergency exits
• Available in all housing variants

Further benefits:

• Greatest possible safety in case of emergency for all user groups in the building
• Reliable system with high number of cycles tested
• Simplicity in practice thanks to central control, visualisation and monitoring of door statuses, access authorisations, etc.
• Simple and flexible integration into other systems is also possible at a later date, e.g. messages to higher-ranking building management systems
• Carefully considered construction of the entire system

Compact experts for safe solutions

Product features // Compact

• Plastic housing (THZ) or metal housing (THZ Comfort) with integrated smoke and heat extraction and ventilation buttons
• Compact staircase control units with an output power of 4.5 A
• New connector for the motor line makes wiring much easier
• Individual adjustment with parameter settings (ST220 interface)

GEZE smoke and heat extraction solutions ensure safety wherever only smoke dissipation is needed under building regulation, such as in stairwells. The optimised THZ N4 and THZ Comfort N4 emergency power control units with 4.5 A output current can be discreetly installed even in narrow stairwells. They now offer even more power for more safety. They can be connected to a complete smoke dissipation solution as well as being used for day-to-day ventilation. The signals can also be forwarded to the building management system, for example. Wind or rain sensors can be connected to the control units without the use of additional modules – so windows close safely, even in the event of rain or strong wind.

Efficient and safe building automation and control system for GEZE products.

We deliver a standardised, open communication solution for integrating doors, windows and security into all areas of building management. The central device is a standard controller (PLC). The hardware components consist of an embedded PC control system that has a certified BACnet communication interface. This means our products can be integrated into all commonly available building management system, physical security information management system, and CAFM systems. Because of the open standard used, a wide range of interoperable applications can be created with other trades, such as blinds, weather station, heating, ventilation, or room automation.

myGEZE Control at a glance

• Integration of GEZE products into the building automation via BACnet
• Up to 200 GEZE products can be connected, depending on the hardware configuration
• Secure data exchange via the BACnet and KNX communication standard
• BTL certified in accordance with BACnet standard ISO 164845
• Powerful hardware for installation in control cabinets (top-hat rail mounting)
• BACnet device profile BACnet Building Controller B-BC

https://connectivity.geze.com/en

Safe ventilation with power-operated windows

IQ box Safety is a product solution for safe ventilation. Certified by TÜV (a German technical service organisation), IQ box Safety offers the highest level of safety for power-operated windows up to protection class 4.

IQ box Safety is suitable for protecting closing edges on automated windows with 24 V IQ windowdrive drives and enables safety edges and contactless sensors to be connected. For each window, one IQ box Safety connects up to four window drives and two locking drives. It is suitable for natural ventilation and smoke & heat extraction systems, as well as for all activations (such as SHEV control panels, 24 V power supplies, KNX, IQ gear). This therefore allows planners and architects greater flexibility and creative freedom in the layout of ventilation windows and smoke & heat extraction windows.

Benefits

• Fulfils the requirements of the highest protection class in accordance with risk assessment
  for power-operated windows under the Machinery Directive (protection class 4)
• TÜV-certified functional safety in accordance with DIN EN 13849-1
• Quick and simple commissioning with pre-set standard parameters
• Four sensor connections that can be assigned to switch strips or non-contact sensors
• Top hat rail module with pluggable terminals for quick and simple wiring
• Integrated push button for manually closing windows during servicing
