Luxtella OP mini - LO Series

This luminaire is suitable for urban city centres, where beside technical elements also design is important. Metal parts are made of cast aluminium and powder coated. Diffusor is made of UV resistant PC and ensures good light transmittance. Luminaire is IK8 and IP65 compliant. Optionally, can be equipped with milky diffusor. We can use symmetrical or asymmetrical optics. Standardly equipped with 0,5 m cable. It can be directly installed on poles with 60 mm diameter.

This is sub version of Luxtella street LB series. It is equipped with special holder that enables to connect the luminaire on celling of industrial objects or warehouses. Silicone gaskets
ensure IP66 protection, whole fi xture is IK10 resistant. Luminaire is ENEC certifi ed. Usually we use one of symmetrical optics (10°, 20° or 60°) and special optic for installation in warehouse between aisles.

Solar sets are always subject of customised off er and consist of several elements that could be delivered:
- LED luminaire (can be LB or LO series)
- PV panel (we off er 275W as a standard)
- Lithium Battery (typically we off er 12V, 40Ah, LiFePo4)
- Charge controller & LED driver - 12V (maximum 80W lamp), 24V (more than 80W lamp)
- PV panel and battery holder
- Holder of luminaire
Autonomy of solar luminaires is adjusted with the size of battery.
With GPS coordinates we can optimize a solar luminaire set to best suite any desired location on Earth.

We off er modular building concept in lighting business. With basic elements we can off er standard street luminaire, hanging type, T-lamp or also industrial luminaire all made from same or similar components. Housing is made of extruded aluminium with 20 microns anodised fi nish that enables perfect heat transfer. Each end is covered with die cast parts. Access to the cable is possible without tools, replacing the driver is easier. Silicone gaskets ensure IP66 protection, whole fi xture is up to IK10 resistant. Optionally, luminaire can be equipped with Zhaga or NEMA socket. Universal holder enables top pole or side entry installation with possibility to change inclination for + / - 15 deg with step of 5 deg. Regularly equipment is a 60 mm pole connector, 76 mm also available. All screws are made of stainless steel.

This luminaire is suitable for urban city centres, where beside technical elements also design is important. Metal parts are made of cast aluminium and powder coated. Diffusor is made of UV resistant PC and ensures good light transmittance. Luminaire is IK8 and IP65 compliant. Optionally, can be equipped with milky diffusor. We can use symmetrical or asymmetrical optics. Standardly equipped with 0,5 m cable. It can be directly installed on poles with 60 mm diameter.

This is sub version of Luxtella street LB series. It is equipped with special holder that enables to connect the luminaire on celling of industrial objects or warehouses. Silicone gaskets
ensure IP66 protection, whole fi xture is IK10 resistant. Luminaire is ENEC certifi ed. Usually we use one of symmetrical optics (10°, 20° or 60°) and special optic for installation in warehouse between aisles.

Solar sets are always subject of customised off er and consist of several elements that could be delivered:
- LED luminaire (can be LB or LO series)
- PV panel (we off er 275W as a standard)
- Lithium Battery (typically we off er 12V, 40Ah, LiFePo4)
- Charge controller & LED driver - 12V (maximum 80W lamp), 24V (more than 80W lamp)
- PV panel and battery holder
- Holder of luminaire
Autonomy of solar luminaires is adjusted with the size of battery.
With GPS coordinates we can optimize a solar luminaire set to best suite any desired location on Earth.
