Cable reel with an innovative anti-twist system (fixed sockets), a unique metal CUBE stand and an overload protection (thermal switch). It is equipped with a rubber, oil resistant H07RN-F cable which is 40m long. It has four grounded sockets with current circuit protection and sealing covers that protect the device against dust, dirt and water. Moreover it has a handy, rubber carrying grip, a rotary drum winding handle, reel rotation lock and an insulated IP 44 plug. Designed for challenging conditions and suitable for outdoor use.

The 3-phase energy meter with a maximum current of 80A is a modern measuring device designed for precise monitoring of electricity consumption in three-phase installations. The meter can be used for commercial, industrial and domestic applications where accurate and reliable readings are required.

The meter operates in systems with a rated voltage of 3x230V or 400V AC and a frequency of 50Hz, enabling direct energy measurement without the need for current transformers. The device records active, consumed and emitted energy. This allows for comprehensive monitoring of energy flow in both directions. A minimum measurement current of 0.25A ensures high sensitivity of the device even at low load, and a starting current of 0.02A allows even small current draws to be recorded.

The digital LCD display (6+2 digits) with a backlit allows comfortable readings even in low light. The unit also has an active energy sub-meter reset function, particularly useful in situations requiring periodic resetting of readings.

Designed for mounting on a TH-35mm DIN rail, it ensures easy installation in standard switchboards. The 76x100x65 mm enclosure accommodates 4.3 DIN modules as standard. The maximum cross-section of the connection cables is 35 mm².

The meter supports the IR protocol in accordance with EN 62056-21.

It is possible to set 27 different parameters to be displayed on the LCD screen. This requires the use of a USB optical head (OR-WE-518) to enable communication between a PC (Windows) and electricity meters equipped with IR optical ports. A simple application allows the data meter to be downloaded and programmed (including setting tariffs). Baud rate: 300, 600, 1200, 2400, 4800, 9600, 19200 bits/sec. Operates in accordance with IEC 62056-21 (IEC1107).

The meter has been designed in accordance with standards: EN 50470-3:2022, EN IEC 62053-21:2021, IEC 62052-11:2020, IEC 62052-31:2015. Compliance with MID 2014/32/EU allows the meter to be used in commercial spaces where certified equipment used for billing is required.

The recessed furniture socket with a flat milled edge is not only a practical solution for connecting appliances, but also an elegant addition to any modern interior. It is perfect both for home and workplace use.

The two Schuko-type sockets (2P+E) and a 1.5 m cable provide flexibility in installation, while the 1.5mm2 conductor cross-section guarantees safe operation. It is equipped with two USB ports (type A and type C; 5V/3.6A) to connect additional mobile devices, such as a phone or tablet.

The socket is made of high-quality plastic and aluminium, making it resistant to damage.

The socket is in black with a rectangular shape. Dimensions: 284x103x56 mm. The thickness of the edge is 7 mm. Dimensions of the mounting hole: 270x73 mm.

Also available with a French-type socket.

Recessed furniture connection panel NOEN is composed of an empty aluminium case and an integrated PVC frame. It is a convenient solution that enables installation of 3 NOEN socket or port modules (45x45mm each) or 6 modules (22.5x45mm each), in combination that suits preferences of the user (power sockets, HDMI, USB, RJ45, RJ11). This connection panel can be integrated into the surface of conference tables, office desks and kitchen tables. It has a protective cover and a cable 1.5m long. Available colours: white, black, silver.
