LanTEK IV-S Cable Certification System for acceptance measurements Cat. 5 to Cat. 8.1/8.2

VDV II series and PoE Pro verifier Cloud-Connected with Bluetooth/report function for basic testing of the IT cabling structure. The VDV II series is easy to use and allows the verification of copper cables of voice, data and video installations, such as telephone lines, data lines and video/security systems, of residential and commercial buildings. Real-time storage of test results through the free AnyWARE Cloud App on the mobile device and seamless transfer to the AnyWARE Cloud for professional reporting. The integrated tone generator enables cable tracing with a compatible inductive receiver. Optional remote adapter kits are available for efficient work and testing on multiple connections.

The new "Cloud Connected" class with Bluetooth/report function for professional reporting.

Wiring test
Precise fault localization
TDR
Length determination
PoE detection
Immediate result output
Determination of the network rate up to 10G ●
Voltage warning
Built-in tone generator
Port identification/hub link

(functions depending on model)

FiberMASTER fibre optic splicers are indispensable for creating reliable, long-lasting fibre optic connections and offer outstanding splicing performance in just approx. 6 seconds. With high repeatability, your last splice will be just as accurate as your first. With the extensive range of accessories, including a fibre cleaver, stripping tools, cleaning tool, workstation lamp and replacement electrodes in a sturdy transport case that can be used as a work platform, you have almost everything you need to get started. It has never been easier to protect your investment with reliable customer support and a standard 3-year warranty. Additional accessories such as crimping tools, holders and crimping protection in accordance with TS 0338/96 are also available.

S60 - Active Core Alignment Splicer
S60 delivers superior low loss and repeatability when splicing dissimilar fibre types using automated
detection. Using 2 additional camera motors (6 motors total) to optimise core detection and provide
precise alignment for ultimate repeatability with any type of fibre.
Optimised for – Trunk networks, telecom and high volume splicing.
Fast Splice Time - 6 sec (Avg.)
Magnification and Resolution - 400x
Touch Screen - 5” Colour LCD
Heating Time - Typical 18 sec
Battery Capacity - 280 splice/heat cycles
Data storage - 10,000 results

S40 - Adaptive Clad Alignment Splicer
S40 delivers superior speed and splice performance in fibre optic installations where fibres of similar types are spliced. Using 4 motors for precision cladding alignment of any type of fibre providing fast splicing and dependable performance.
Optimised for – Fibre to the home (FTTH), access networks, enterprise and campus networks.
Fast Splice Time - 7 sec (Avg.)
Magnification and Resolution - 320x
Touch Screen - 4.3” Colour LCD
Heating Time: Typical 20 sec
Battery Capacity: 240 splice/heat cycles
Data storage: 8,000 results

Pressure on networks is increasing and downtime is expensive. Fix it fast with SignalTEK 10G.

The SignalTEK 10G measures the maximum bandwidth of the network cabling up to 10 Gigabits per second. By simulating actual network traffic users can test, troubleshoot and document network and data cable performance up to 10 Gigabit Ethernet standards. SignalTEK 10G has built-in Wi-Fi connectivity to connect seamlessly to the free TREND AnyWARE Cloud test management system. AnyWARE Cloud offers pre-configuration to eliminate errors on-site, label printer connectivity to save time and “proof of performance” PDF reports for the clients.

Why do I need a 10G Ethernet Tester?

Problem
LAN networks are at risk of expensive downtime and lost productivity due to the ever-increasing demand of bandwidth hungry services such as video streaming, video conferencing, CCTV cameras and Wi-Fi access points.

Solution
SignalTEK 10G will measure the maximum bandwidth available of the network, identify bottlenecks and discover opportunities to increase bandwidth without replacing expensive data cabling.

Avoid network downtime
Troubleshoot Ethernet connectivity issues faster using diagnostic tools.
Pinpoint bottlenecks faster
Discover which part of your network is causing the bottleneck.
Validate network upgrades
Verify Multi-Gigabit switch upgrades to 2.5/5 and 10Gb/s speeds.
Prove the maximum bandwidth
Provide “proof of performance” PDF reports to the client.

SignalTEK 10G offers the extensive features of a wiremapper, network tester, PoE tester and 10G transmission tester, as well as options for fiber optic testing and advanced network testing, depending on the model. The additional features can also be activated at a later time if required via a simple license key, two upgrade options – fiber optic tests and advanced network tests – are available.

Specification:

Speed

• Max bandwidth test up to 10Gb/s
• Data transmission test 2.5/5/10Gb
• NbaseT/mutigig validation 2.5/5/10Gb

Test

• Distance to fault and length
• Cable tracing (with compatible probe)

Verify

• Pass / Fail to copper and fibre Ethernet standards

Fibre

• Optical Rx power indication

PoE

• Pass / Fail to PoE IEEE standards
• Displays voltage and which pairs have PoE
• Measures max power available (up to 90 watts)
• Identifies Power Sourcing Equipment Class – 0 to 8
• Identifies Power Sourcing Equipment Type (af/at/bt)

Network

• Switch Speed - 100M, 1000M, 2.5G, 5G, 10G
• Hub blink VoIP Testing with jitter and delay
• VLAN ID detection 72 hour event log
• Prove actual network performance (up to 10G)
• CDP/LLDP/EDP port information
• PING and TraceRoute

The new SignalTEK QT Series is the ultimate 10G qualification tester for copper (QT) or copper, fibre, and WiFi diagnostics (QT Pro). Powered by TREND AnyWARE Cloud, enabling remote reporting and test result analysis.
As networks evolve to support higher bandwidth, lower latency, and increased device density, 10 Gigabit Ethernet is rapidly becoming the standard for future-proof LAN infrastructures. The transition to fibre optic backbones and the growing demand on WiFi networks require precise, reliable and scalable testing
solutions, which is exactly what the SignalTEK QT delivers. The SignalTEK QT Series was designed for today’s Copper, Fibre and WiFi networks.

• Copper Cable Qualification - Qualify performance from 10Mb/s to 10Gb/s including Multi-Gig speeds with
  Live wiremap and TDR fault location.
• Fibre Cable Qualification - Qualify performance from 10Mb/s to 100Gb/s by measuring dB loss and
  length to IEEE standards (QT Pro).
• WiFi Channel Scan and Utilisation - Select a channel to view the name, IP address, MAC address and signal strength of APs on each channel to help balance utilisation (QT Pro).
• PoE Load Test - Ensure installed cables provide enough power for PoE devices by performing a
  load test with up to 90 watts including Pass/Fail results.
• Device Scan - Connect to active copper/fibre/WiFi networks and collect a list of connected
  devices including the vendor ID, IP address and MAC address with automatic checking for IP address conflicts.
• Access Point Location - Use the internal or external antennas to locate hidden access points with the
  responsive signal strength indicator (QT Pro).
• Create professional reports with the TREND AnyWARE Cloud.
