SignalTEK 10G Ethernet Troubleshooter and Bandwidth Tester

The new SignalTEK QT Series is the ultimate 10G qualification tester for copper (QT) or copper, fibre, and WiFi diagnostics (QT Pro). Powered by TREND AnyWARE Cloud, enabling remote reporting and test result analysis.
As networks evolve to support higher bandwidth, lower latency, and increased device density, 10 Gigabit Ethernet is rapidly becoming the standard for future-proof LAN infrastructures. The transition to fibre optic backbones and the growing demand on WiFi networks require precise, reliable and scalable testing
solutions, which is exactly what the SignalTEK QT delivers. The SignalTEK QT Series was designed for today’s Copper, Fibre and WiFi networks.

• Copper Cable Qualification - Qualify performance from 10Mb/s to 10Gb/s including Multi-Gig speeds with
  Live wiremap and TDR fault location.
• Fibre Cable Qualification - Qualify performance from 10Mb/s to 100Gb/s by measuring dB loss and
  length to IEEE standards (QT Pro).
• WiFi Channel Scan and Utilisation - Select a channel to view the name, IP address, MAC address and signal strength of APs on each channel to help balance utilisation (QT Pro).
• PoE Load Test - Ensure installed cables provide enough power for PoE devices by performing a
  load test with up to 90 watts including Pass/Fail results.
• Device Scan - Connect to active copper/fibre/WiFi networks and collect a list of connected
  devices including the vendor ID, IP address and MAC address with automatic checking for IP address conflicts.
• Access Point Location - Use the internal or external antennas to locate hidden access points with the
  responsive signal strength indicator (QT Pro).
• Create professional reports with the TREND AnyWARE Cloud.

VDV II series and PoE Pro verifier Cloud-Connected with Bluetooth/report function for basic testing of the IT cabling structure. The VDV II series is easy to use and allows the verification of copper cables of voice, data and video installations, such as telephone lines, data lines and video/security systems, of residential and commercial buildings. Real-time storage of test results through the free AnyWARE Cloud App on the mobile device and seamless transfer to the AnyWARE Cloud for professional reporting. The integrated tone generator enables cable tracing with a compatible inductive receiver. Optional remote adapter kits are available for efficient work and testing on multiple connections.

The new "Cloud Connected" class with Bluetooth/report function for professional reporting.

Wiring test
Precise fault localization
TDR
Length determination
PoE detection
Immediate result output
Determination of the network rate up to 10G ●
Voltage warning
Built-in tone generator
Port identification/hub link

(functions depending on model)

FiberMASTER fibre optic splicers are indispensable for creating reliable, long-lasting fibre optic connections and offer outstanding splicing performance in just approx. 6 seconds. With high repeatability, your last splice will be just as accurate as your first. With the extensive range of accessories, including a fibre cleaver, stripping tools, cleaning tool, workstation lamp and replacement electrodes in a sturdy transport case that can be used as a work platform, you have almost everything you need to get started. It has never been easier to protect your investment with reliable customer support and a standard 3-year warranty. Additional accessories such as crimping tools, holders and crimping protection in accordance with TS 0338/96 are also available.

S60 - Active Core Alignment Splicer
S60 delivers superior low loss and repeatability when splicing dissimilar fibre types using automated
detection. Using 2 additional camera motors (6 motors total) to optimise core detection and provide
precise alignment for ultimate repeatability with any type of fibre.
Optimised for – Trunk networks, telecom and high volume splicing.
Fast Splice Time - 6 sec (Avg.)
Magnification and Resolution - 400x
Touch Screen - 5” Colour LCD
Heating Time - Typical 18 sec
Battery Capacity - 280 splice/heat cycles
Data storage - 10,000 results

S40 - Adaptive Clad Alignment Splicer
S40 delivers superior speed and splice performance in fibre optic installations where fibres of similar types are spliced. Using 4 motors for precision cladding alignment of any type of fibre providing fast splicing and dependable performance.
Optimised for – Fibre to the home (FTTH), access networks, enterprise and campus networks.
Fast Splice Time - 7 sec (Avg.)
Magnification and Resolution - 320x
Touch Screen - 4.3” Colour LCD
Heating Time: Typical 20 sec
Battery Capacity: 240 splice/heat cycles
Data storage: 8,000 results

The LanTEK IV-S is a new Cable Certification System that brings a new standard to the industry, making the job faster, easier and more profitable.

The new LanTEK IV-S technology provides faster test times. Engineers and technicians can conduct and save a Cat. 6A test within 7 seconds, assisted by the intuitive user interface and easy to use high resolution touchscreen. In addition, the tester's enhanced functionality certifies links up to Cat. 8, including TCL/ELTCTL and Resistance Unbalance and will sweep to 3000 MHz providing room for future ratified ISO and TIA test standards.

LanTEK IV-S also provides the patent pending VisiLINQ permanent link adapter, a new and unique way to test that allows users to initiate testing and view the results without even needing to hold the certifier. This allows technicians to work smarter, saving time and increasing productivity. The RJ45 tip on the VisiLINQ Permanent Link Modules are also field replaceable to reduce the cost of ownership.

For example, the tough new LanTEK IV-S cable certifier can connect to Wi-Fi and to the new TREND AnyWARE Cloud test management system to enable real time collaboration between Project Managers and Field Technicians. This new functionality enables project information and test setup to be pre-configured, saving time and eliminating potentially costly setup errors. TREND AnyWARE Cloud also makes it quicker and easier than ever to prepare and share reports for customers and warranties.

With enhanced connectivity, LanTEK IV-S also makes Live support possible. Colleagues, cable manufacturers and our Technical Support team can all connect to LanTEK IV-S remotely, helping to increase collaboration, minimise troubleshooting time and reduce call-backs.

We have been developing high quality cable certifiers for 26 years and have brought many firsts to the industy. With the new LanTEK IV-S we over another unique innovation which sets new standards and will change the way we certify, now and in the future.

• VisiLINQ Permanent Link Adapter enables Field Technicians to initiate testing and view the results all without the need to carry or touch the certifier.
• 7 seconds test time - Test a Cat. 5e / 6 / 6A cable within 7 seconds.
• Certify Cat. 8 cabling - Including TLC/ELTCTL, CD NEXT (Common/Diffential NEXT), Resistanace Unbalance.
• Model LanTEK IV-S-3000 measures up to 3000 MHz for future ISO and TIA test standards.
• TREND AnyWARE Cloud / Desktop Software.
• Partner Finder - Provides audible tone and visible indicator when connected to the remote unit.
• Live Wiremap - Instand wiremap result before the Autotest begins.
• Label Printer Connectivity - Easily send label IDs to printers for fast and accurate labelling.
• Team Viver Live Support - Using the TREND AnyWARE Cloud users can connect ot a LanTEK IV-S remotely to troubleshoot failed links.
