Trade fair innovationUP¹ – The new standard. Designed by craftsmen, made by KAISER.
UP¹ – The new standard. Designed by craftsmen, made by KAISER.
UP¹ is the new flush-mounting range for electrical installations. Users can choose between classic installation with plaster or quick-fix installation, and between simple installation and air-tightness, and then enjoy all the practical advantages of the new UP¹ family. Advantages such as the side-neutral and stable combination, open through-wiring and break-out separator, floor-level entries, floor-level through-wiring and 4x3 screw domes, which were introduced with the UP¹ ECON® Fix, are now found throughout the entire range. Quick fixing using clamping ribs in all blocks saves up to 50% of installation time without the use of plaster or PU foam. These boxes also offer 25% more installation volume compared to conventional Flush-mounting one-gang junction boxes.
Advantages of all boxes in the UP¹ family (UP¹, UP¹ ECON®, UP¹ Fix, UP¹ ECON® Fix):
- Stable and side-neutral combination
- Open and versatile through-wiring
- Fully insulated through-wiring close to the floor for deep boxes
- 4 triple expanding claw fields / screw domes for secure hold
- Entries in the box base and cable and pipe feed-throughs close to the base
- Triple pipe feed-through M25 from one direction to device and one-gang junction boxes
- Entries up to M32 on electronics boxes and two-gang junction boxes, combination openings M20/M25
- Combination openings M20/M25
Advantages of boxes with ECON® membrane: (UP¹ ECON®, UP¹ ECON® Fix):
- Air-tight design with ECON® multi-membrane
- Prevents leaks in exterior walls made of hollow chamber blocks
- Variable and toolless cable and conduit entries
Advantages of boxes with quick fixing (UP¹ Fix, UP¹ ECON® Fix):
- 25% more volume compared to conventional one-gang junction boxes
- Quick installation in all wall structures (box variants with clamping ribs on the box, no installation of accessories, use of PU foam is possible)
- No mandatory use of PU foam – boxes hold in place thanks to quick fixing
- Stepless plaster compensation (accessories for device and one-gang junction boxes UP¹ Fix or UP¹ ECON® Fix)
With built-in responsibility.
Through the use of recycled granulate and well-thought-out product design, KAISER makes a certified contribution to resource conservation – without compromising on quality, function and safety.
- Made from recycled material. All flush-mounting boxes in the UP¹ family are made from recycled granulate and stand for the responsible use of resources.
- Less additional material on the construction site. UP¹ Fix and ECON® Fix boxes do not require plaster or installation foam – this reduces material usage and waste.
- Tested sustainability: Our UP1 flush-mounting boxes have been tested for harmful substances by the Sentinel Holding Institute and can be integrated into sustainable construction projects with the SHI product passport.
